2026 YAMAHA 25HP LONG SHAFT, ELEC/MAN
Outboard Motor | Yamaha
Stock #BT-90084695B
Model25hp Long Shaft, Elec/Man
Features
Key Features
- Head of the class: The powerful, twin-cylinder in-line 432cc engine powers you through the day.
- Easy does it: Built in resting pads for easy storage
- Variable Trolling RPM: Adjust the engines trolling speed from 750 to 1050 RPM with built in tiller handle controls or through a Command Link display.
RELIABILITY/DURABILITY
- CDI Microcomputer
- Wet Sump Lubrication
- Engine Warning System
- Mechanical Single Throttle Valve Intake System
- SST Drive, Prop, Shift Shafts
- SST Steering Tube
- Magnetic Drain Plug
- Sacrificial Anodes
- YDC-30 Aluminum Alloy
- Phaze Five™ Paint System
- Electro-deposited Powerhead Paint Process
POWER/PERFORMANCE
- New Light-weight, Compact, Powerful Design
- Single Overhead Camshaft
- Battery-less Electronic Fuel Injection
- Wide-Span Mounting System
CONVENIENCE/CONTROL
- High-Output (16-Amp) Alternator
- Electric and Pull-Start Available Together (some models)
- Retrofit Electric Start Available
- 45-Degree Steering in both Directions
- Built-In Resting Pads and Carry Handles
- Variable Trolling RPM Switch (VTSTM )
- Power Trim & Tilt (LWTC model)
- Freshwater Flush
- Spin-on Oil Filter
- Offset Steering Friction Lever
- Auto Decompression Device
- Vibration Reduction Mounting System
- C.A.R.B. Ultra Low Emissions 3 Star Rating
- Meets All Current Federal EPA Emission Standards
- External Oil Drain Plug
Specifications
| Colour | Bluish Gray MetallicPearlescent White |
| Cooling | Water/Thermostatic Control |
| Exhaust | Through Propeller |
| Ignition | CDI Microcomputer |
| Starting | Manual or Electric |
| RPM Range | 5000-6000 |
| Dry Weight | F25SMHC = 57 kg / 126 lbs F25SWHC = 60 kg / 132 lbs F25SWHTC = 66kg / 146 lbs F25LMHC = 59 kg / 130 lbs F25LWHC = 62 kg / 137 lbs F25LWHTC = 67kg / 147 lbs F25SWTC = 64kg / 141 lbs F25LWTC = 65 kg / 143 lbs |
| Gear Ratio | 27:13 / 2.08:1 |
| Gear Shift | F/N/R |
| Engine Type | Two-Cylinder, In-line |
| Lubrication | Wet sump |
| Displacement | 432cc / 26.4ci |
| Oil Capacity | 1.1L / 1.0L (w/without filter) 1.2qt / 1.05qt (w/without filter) |
| Shaft Length | S=15" L=20" |
| Bore & Stroke | 5 x 65.1mm / 2.554 x 2.558in |
| Fuel Delivery | Battery less EFI |
| Recommended Oil | Yamalube® 4-M 10w-30 |
| Induction System | SOHC, 2 valves per cylinder |
| Recommended Fuel | Regular Unleaded (Minimum Pump Octane 87) |
| Alternator Output | 16 amp |
| Compression Ratio | 9.3:1 |
| Degree Of Trim/Tilt | -3° through +16° (PTT) 4 positions (manual tilt) -3° through +63° (PTT) -4 through +62° (manual tilt) |
